| No. | Name | Qty |
| 1 | HFC Serial Variable Frequency Power Source (sin wave or square wave) | 1 set |
| 2 | HET Serial Exciter transformer | 1 set |
| 3 | HFRS-T Serial Tank Type Frequency Resonant Reactor | 1 set |
| 4 | HVF Serial Capacitive Voltage Divider | 2 set |
| 5 | HIP Serial Current Limit Inductance | 1set |
| 6 | HRC Serial Load Capacitor (Option) | 1set/2set |
System color can be customized according to requirement.
System Layout Diagram (with divider on the trailer.)
System Principle Diagram:
HFRS-T serial, HV Frequency Resonant Test Reactor:
HET serial Exciter Transformer:
HVF Serial Coupling Capacitor & High Voltage Filter:
HCRS-C serial Cylinder type on-site resonant test system also available: (below photo are variable inductance system, if need frequency reactor, system will be smaller than the photos.)
Such kind of cylinder, can also realize serial connection for much higher voltage:
HIMALAYAL provides innovative products that comprise high voltage test equipment, full-set high voltage test instruments, on-site test systems and on-line monitoring systems, and services regarding tests, diagnostics and asset monitoring for clients in power industry. We help to ensure safety and reliability in the power generation, transmission and distribution.
